By matching oversize and grippy 20" ‘Plus’ tyres to a rigid fork, we’ve made a kid’s specific monster truck that delivers all of the fun, but without the weight.
Find Dealer
  • THIS IS AN ARCHIVED MODEL

  • VIEW ALL CURRENT MODELS
  • The MATTS J20 Plus is a fat-tyred monster truck that offers the control and grip of chunky 20" oversize tyres, paired to a rigid fork that keeps excess weight to the absolute minimum. Add in our kids specific finishing kit, powerful hydraulic disc brakes and a smooth Shimano drivetrain and you’ve got an awful lot of fun without the fat. Suits heights from approx. 109-129 cm tall.

    Our MATTS J range is designed for the heroes of tomorrow, which is why we put all the know-how gained from years of making adult bikes into lightweight, high-quality machines for kids to enjoy. High-quality components chosen specifically for the needs of children are married to our aluminium frames that are created with the same painstaking attention to detail and quality of finish as the rest of our bikes. That’s the only way to guarantee that young riders get the same enjoyment of cycling, safe in the knowledge that their bike will never let them down. Whatever your age, your level of ability or your size, we have the perfect first MERIDA ready for you. See you on the start line!

    • Lightweight double butted aluminium frame
    • Grippy, oversize ‘Plus’ 20” tyres for extra comfort and control
    • Rigid fork helps keep weight down
    • Shimano drivetrain
    • Hydraulic disc brakes
    • Kid specific finishing kit
    • material: aluminium
    • 20x2.4" max. wheelsize
    • 135x9/100x9 mm axle standard
    • BSA bottom bracket standard
    frame size 10"
    color FALL GREEN (RED/BLACK)
    • material: aluminium
    • 20x2.4" max. wheelsize
    • hydraulic brake
    headset FSA NO.10P Neck15
    • material: aluminium
    • 620 mm width
    • 0 mm rise
    • material: aluminium
    • 31.8 mm diameter
    • 6° stem angle
    • 60 mm
    grip MERIDA EXPERT JR
    derailleur (r) Shimano RD-M310
    shifters Shimano SL-M315-7
    • 27.2 mm diameter
    • 0 mm setback
    • material: aluminium
    seat clamp MERIDA COMP QR
    saddle MERIDA COMP JR
    pedal Marwi SP-202
    chain KMC NS8
    • 28 teeth
    • MAT Aluminium
    • 127 mm
    • 14-34 teeth
    • 7 speed
    bottom bracket FSA TH-7420ST, 68-124
    • 100x9 mm width front hub
    • 20 spoke holes
    • 135x9 mm width rear hub
    • 24 spoke holes
    • material: aluminium
    spokes Black steel
    kickstand kickstand adjustable alloy
    • weighed at frame size UNI
    • Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
    • Total weight of bike, rider and luggage
    Bike Frame Geometry Image
    Frame Size 10"
    Tyre Sizes 20"
    ST seat tube [mm] 240
    TT top tube [mm] 445
    CS chain stay length [mm] 360
    HTA head tube angle [°] 68
    STA seat tube angle [°] 72
    BD bottom bracket drop [mm] 20
    HT head tube [mm] 120
    FL fork length [mm] 340
    R reach [mm] 305
    S stack [mm] 432
    WB wheel base [mm] 872
    SH stand over height [mm] 483

    To reduce production and delivery times, we are sometimes forced to make last-minute specification changes. Please be aware that those changes might not be reflected on these product pages and images.



    Technologies

    Back to overview

    RACELITE 61 ALUMINIUM

    We use a minimum of 6061 grade aluminium on all our bikes. It’s particularly well suited to being shaped with our hydroforming and technoforming processes, which allow us to vary the wall thickness to create double-butted tubing and complex frame shapes. It’s also an alloy that welds easily, and once it has been carefully heat treated to maximise strength, it means we can create strong and lightweight bicycle frames for you to enjoy.

    Watch Video
    Back to overview

    F-MOUNT

    Being able to turn your bike into an all-weather commuter that has mudguards and other fittings can be a real plus, in particular when riding on wet and perhaps muddy roads and tracks on a regular basis. To make fitting easy, some of our bikes are F-MOUNT equipped. These integrated fittings mounts make adding mudguards fast and simple. Please note that some bikes require model-specific mudguards.

    Watch Video
    Back to overview

    K-MOUNT

    When using your bike in an urban environment, where you might not always have the option to use a specific bike stand, a kickstand is an ideal solution to park your bike safely. Some of our bikes come with a neatly integrated K-MOUNT, which makes fitting a MERIDA kickstand (or any commercial kickstand) easy. And if you don’t want to have a kickstand and prefer the clean appearance of your frame, the K-MOUNT is neatly tucked away underneath your chainstay, difficult to spot if you don’t know it is there.

    Watch Video
    Back to overview

    C-MOUNT

    Similar to our F-MOUNT, where various fixing points for mudguards are part of the frame offering, the C-MOUNT equipped bikes have the fixing points for a rear rack already integrated, making fitting fast, simple and reliable. The C-MOUNTS are an additional feature that improves the day-to-day versatility by adding loading capacity to your bike, ideal for commuting and shopping trips. Please note that some bikes require model-specific rear racks.
