- material: aluminium
- 29"x2.4" with fender max. wheelsize
- 148x12mm axle standard
- intube
Rammestørrelse S, M
Farge GUNMETAL GREY (BLACK)
- Air
- 120mm suspension travel
- 29x2.4" max wheelsize
- 4 piston
- 4 piston
Styrelager Acros ICR MERIDA INTEGRATED neck w/ Blocklock
Holker / styretape MERIDA EXPERT TK
Fremre girhendel Shimano SL-MT500-L
Bakre girhendel Shimano Cues U6000-10
- 34.9mm diameter
- 0mm setback
- S/M/L/XL: 150mm travel seatpost
Sadelklemme MERIDA EXPERT
*24% recycled material V-mount
Pedal VP VPE-541P
Kjede Shimano LG500
- 165mm for all sizes
- 11-48 teeth
- 10 speed
- 110x15mm width front hub
- 148x12mm width rear hub
- 28mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 29"
- 622-55
- wire
- reflecting line
- 622-55
- wire
- reflecting line
- 15x100mm width front hub
- 32 spoke holes
- Centerlock
- 12x148mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
Skjermer Sunnywheel SW-FA311-65A/ SW-FA311-65E1
Eiker Black stainless
- reverse MERIDA Custom Mount
bagasjebrett MERIDA MIK HD Carrier with Spring clip & Spanninga rear light
støtte Massload CL-KA85
motor Bosch Performance Line CX
- removeable
batterilås Abus Key
display Bosch Purion 200
batterilader Bosch 4A Charger (220-240V)
rammelås Abus 4650 XL
| Rammestørrelse | S | M |
| Dekkstørrelse | 28" | 28" |
| ST - Seat Tubes (mm) | 380 | 430 |
| TT - Top Tube (mm) | 588 | 605 |
| CS - Chain Stays (mm) | 475 | 475 |
| HTA - Head Tube Angles (°) | 115 | 120 |
| STA - Seat Tube Angle (°) | 67.5 | 67.5 |
| BD - Bottom Bracket Drops (mm) | 62.5 | 62.5 |
| HT - Head Tube Length (mm) | 115 | 120 |
| FL - Fork Length (mm) | 538 | 538 |
| R - Reach (mm) | 408 | 425 |
| S - Stack (mm) | 647 | 651 |
| WB - Wheel Base (mm) | 1176 | 1194 |
| SH - Stand Over Height (mm) | 646 | 656 |
| Str Stack To Reach Ratio Pc | 1.58 | 1.53 |
| Seat Post Mounting Depth Max Mm | 290 | 300 |
