Our top of the range fitness bike is not just loaded with high-end components which offer superior function, longevity and smoothness; it also combines fast and effortless road bike-like ground covering with a less aggressive and strenuous riding position. The perfect bike for sporty outings, fast commuting and even lightweight touring. The carbon fork reduces weight and adds superior vibration absorption. Multiple fixing points allow bottle cages, fenders, kickstand and a rear rack to be fitted.
Fast and lightweight, the SPEEDER shares its genes with our road bike range. The geometry offers an extended reach for added stability while providing a more upright and comfortable riding position. The sporty yet comfort inspired geometry paired with control enhancing flat handlebars and powerful disc brakes make the SPEEDER ideal for fast commuting or fitness rides. Wider tyres and more tyre clearance underline the comfort element even further and give the SPEEDER more grip when it counts. Road.cc call the 900 an 'excellent fast flat-bar road bike with awesome performance' and the 200 'an enjoyable flat-barred flyer for fitness, commuting and everyday riding'.
- Lightweight aluminium frame with full carbon fork
- SRAM wireless single ring chain set drivetrain
- Sporty yet comfortable geometry and seating position
- Flat handlebar setup
- Powerful Shimano hydraulic disc brakes
- Multiple fixing points for fenders, kickstand and a rear rack
- material: aluminium
- 700x35C max. wheelsize
- 100x9/135x9 mm axle standard
- BSA bottom bracket standard
- Tapered
- material: carbon
- 700x35C max. wheelsize
- 2 piston
- 2 piston
- 170 mm-XXS/XS, 172,5 mm-S/M, 175 mm-L/XL
- 11-44 teeth
- 12 speed
- V-mount
- incl. MERIDA minitool
- material: carbon
- 30,9 mm diameter
- 15 mm setback
- 17 mm inner width
- 22 mm height
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 700x32C
- fold
- 700x32C
- fold
- 100x9 mm width front hub
- 28 spoke holes
- centerlock
- 135x9 mm width rear hub
- 28 spoke holes
- centerlock
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
- Total weight of bike, rider and luggage
| Frame Size | XXS | XS | S | M | L | XL |
| Tire Sizes | 28" | 28" | 28" | 28" | 28" | 28" |
| St Seat Tubes Mm | 470 | 500 | 520 | 540 | 560 | 590 |
| Tt Top Tubes Mm | 555 | 561 | 571 | 583 | 597 | 610 |
| Cs Chain Stays Mm | 438 | 438 | 438 | 438 | 438 | 438 |
| Hta Head Tube Angles Deg | 70 | 70.5 | 71 | 71.5 | 72 | 72 |
| Sta Seat Tube Angle Deg | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Bd Bottom Bracket Drops Mm | 65 | 65 | 65 | 65 | 65 | 65 |
| Ht Head Tube Lengths Mm | 150 | 160 | 170 | 190 | 215 | 240 |
| Fl Fork Lengths Mm | 395 | 395 | 395 | 395 | 395 | 395 |
| R Reachs Mm | 389 | 392 | 398 | 404 | 410 | 416 |
| S Stacks Mm | 562 | 573 | 585 | 606 | 631 | 655 |
| Wb Wheel Base Mm | 1051 | 1053 | 1058 | 1066 | 1075 | 1088 |
| Sh Stand Over Height Mm | 744 | 769 | 787 | 806 | 828 | 855 |
