- material: aluminium
- 700x50C (with fender) max. wheelsize
- 142x12mm axle standard
- intube
- max. 504 Wh
- eSPRESSO L XS(43L)-S(47L)-M(51L)-L(55L)
- Coil
- 63mm suspension travel
- 700x52C max wheelsize
- 2 piston
- 2 piston
- 180 mm
- 180 mm
- material: aluminium
- 34.9mm diameter
- 0mm setback
- V-mount
- 38 teeth
- Shimano FC-E6100
- 170 mm
- 11-36 teeth
- 9 speed
- 20mm inner width
- material: aluminium
- 622-50
- wire
- reflecting line
- 622-50
- wire
- reflecting line
- 100x9mm width front hub
- 32 spoke holes
- Centerlock
- 142x12mm width rear hub
- 36 spoke holes
- Centerlock
- including removeable lever, 6mm allen key
- 60Nm
- 500Wh
- 2A charging current
weighed with 700C wheels and at frame size M
| Ramstorlek | XS | S | M | L | XL |
| Däckstorlekar | 28" | 28" | 28" | 28" | 28" |
| ST - Seat Tube (mm) | 430 | 470 | 510 | 550 | 590 |
| TT - Top Tube (mm) | 565 | 580 | 590 | 610 | 630 |
| CS - Chain Stays (mm) | 478 | 478 | 478 | 478 | 478 |
| HTA - Head Tube Angle (°) | 70.5 | 71 | 71 | 71.5 | 71.5 |
| STA - Seat Tube Angle (°) | 75 | 74.5 | 74.5 | 74 | 74 |
| BD - Bottom Bracket Drops (mm) | 70 | 70 | 70 | 70 | 70 |
| HT - Head Tube Length (mm) | 130 | 140 | 155 | 175 | 205 |
| FL - Fork Length (mm) | 475 | 475 | 475 | 475 | 475 |
| R - Reach (mm) | 397 | 403 | 409 | 417 | 429 |
| S - Stack (mm) | 626 | 637 | 651.5 | 672.5 | 701 |
| WB - Wheel Base (mm) | 1114 | 1118 | 1129 | 1138 | 1159.5 |
| SH - Stand Over Height (mm) | 724 | 758 | 793 | 828 | 864 |
| Siffra | Item Number | Namn | Info | Pieces | Torque NM |
| 1 | A2300000048 | SCREW | M4x0.7 L8mm | 1 | 3~5 |
| 2 | A2311000067 | RD-HANGER | DH-057 | 1 | |
| 3 | A2300000129 | SCREW | M3x0.5 L10mm | 2 | 2~4 |
| 4 | A2258000012 | CABLE GUIDE | for M5 fixation | 1 | |
| 5 | A2298000120 | SCREW | M5x0.8 L12mm | 1 | 3~5 |
| 6 | A2300000468 | SCREW | M8x1.25 L18.5mm | 3 | 11~12 |
| 7 | A2300000469 | SCREW | M8x1.25 L23mm | 3 | 11~12 |
| 8 | A2136000017 | MOUNT | for bottle cage | 1 | |
| 9 | A2298000144 | SCREW | M5x0.8 L10mm | 6 | 3~5 |
| 10 | A2298000145 | SCREW | M5x0.8 L20mm | 1 | 3~5 |
| 11 | A2143000097 | BLIND PLUG | 1 | ||
| 12 | A2161000127 | CABLE GUIDE | 1 | ||
| 13 | A2300000500 | COVER PIN | 1 | 3~5 | |
| 14 | A2161000058 | COVER MOUNT | for ENEGRY GUARD | 1 | |
| 15 | A2161000115 | COVER | for 504Wh battery | 1 | |
| 16 | A2300000213 | SCREW | M3x0.5 L13.5mm | 4 | 2~4 |
| 17 | A2143000098 | BLIND PLUG | for key opening | 1 | |
| 18 | A2258000079 | CABLE PLUG | for RD | 1 | |
| 19 | A2258000099 | CABLE PLUG | for rear brake and speed sensor | 1 | |
| 21 | CABLE GUIDE | SMART ENTRY | |||
| 22 | A2143000076 | COVER | for carrier mount | 2 | |
| 23 | A2298000142 | SCREW | M6x1.0 L12mm | 2 | 6~8 |
Highlights
All models ride on fast-rolling 700c wheels, ideal for rides on roads, lanes and smooth tracks. We fit tyres with reflective sidewalls and puncture protection that will get you to your destination quickly and safely. However, our 'classic' eSPRESSO frames can also take 650B wheels if needed.
In our eSPRESSO range, you can choose between two frame options. The frame design with integrated battery technology, or the proven semi-integrated battery frame option, so that you can find the ideal bike for your preferences and your budget. Our integrated battery models come equipped with either the super-powerful EP8 or the more economical E6100 motor, while the semi-integrated battery models feature the entry-level E5000 power unit, giving you even more choice to select the perfect eSPRESSO for your needs.
All our eSPRESSO models come equipped with mudguards, lights, lock, rear rack and a kickstand, making them ready for anything from the moment you leave the store.
A two-component battery cover, which offers the perfect protection for the internal battery of these models. The softer (outer) layer reduces noises, seals the downtube perfectly and absorbs hits from trail debris easily, while the harder (inner) layer ensures that the battery does not get damaged and gives it the structural shape.
The system weight of a bike is the combined weight of bike, rider and additional luggage. The allowed system weight is 140 kg. As an e-bike is already heavier than a regular bike, and as it also makes it easier to transport larger amounts of luggage, it is imperative to certify a higher overall system weight. All MERIDA e-bikes, as well as all used componentry, go through a rigorous and e-bike specific testing schedule which mimics the higher forces and strains to guarantee the rider the highest level of safety.
Vajrar dras genom ramen för att ge snyggare look och för att hålla kablar/vajrar borta från luftflödet och skyddade mot fukt och smuts.
Kablar/vajrar, höljen och bromsslangar spänns när de kläms fast för att slippa missljud när skogsstigen eller vägen blir riktigt ojämn. Alla genomföringar är helt utbytbara vilket gör dem kompatibla med höljen för Di2, hydraulslangar, bromsvajer och växelvajer.
