brakes V-Brake Linear A
frame J24 Alloy
frame size 11.5"
fork HL Suspension 24
color BLACK (GREY/RED)
derailleur (r) Shimano TX
rotors n/a
shifter front Shimano RevoShift 7
shifter rear Shimano RevoShift 7
brake lever Junior Alloy
brake front V-Brake Linear A
brake rear V-Brake Linear A
chain KMC Z50
crank Steel 36 160L DG Silver
hub front Alloy NT
hub rear Alloy NT
rim Alloy Black
freewheel Shimano MF-TZ21 14-28, 7S
tyre front MTB 24 x 1.95" W/White line
tyre rear MTB 24 x 1.95" W/White line
spokes Steel UCP
handlebar stem XM Steel Rise 550
headset A-Head
seat post Alloy 27.2
saddle Matts kid 24
kickstand Alloy center-type
Frame Size | 11.5" |
Tyre Sizes | 24" |
Frame Size Inch | 11.5 |
ST seat tube [mm] | 289 |
TT top tube [mm] | 505 |
CS chain stay length [mm] | 410 |
HTA head tube angle [°] | 69 |
STA seat tube angle [°] | 72 |
BD bottom bracket drop [mm] | 29 |
HT head tube [mm] | 120 |
FL fork length [mm] | 390 |
R reach [mm] | 345 |
S stack [mm] | 492 |
WB wheel base [mm] | 999 |
SH stand over height [mm] | Boy:515/Girl:474 |
Body Height Cm | 130 - 150 |
