- 100mm suspension travel
- material: carbon
- 29x2.3" max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
- Air
- 100mm suspension travel
- Tapered
- Remote lockout
- 51mm fork offset
- 29x2.8" max. wheelsize
- remote lockout
- 2 piston
- 2 piston
- flat mount
- 180mm
- 160mm
- 30.9mm diameter
- 0mm setback
- S/M/L/XL: 100mm travel seatpost
- 32 teeth
- 175mm-M up
- 10-51 teeth
- 12 speed
- 22.8mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 29x2.25"
- fold
- TR EXO 120 TPI
- 29x2.25"
- fold
- TR EXO 120 TPI
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 32 spoke holes
- Centerlock
- including removeable lever, 6/4mm allen key
weighed with 29" wheels and at frame size M, without pedals
| Ramstorlek | S | M | L | XL |
| Däckstorlekar | 29" | 29" | 29" | 29" |
| ST - Seat Tube (mm) | 400 | 440 | 470 | 500 |
| TT - Top Tube (mm) | 576 | 596 | 619 | 643 |
| CS - Chain Stays (mm) | 435 | 435 | 435 | 435 |
| HTA - Head Tube Angle (°) | 68.5 | 68.5 | 68.5 | 68.5 |
| STA - Seat Tube Angle (°) | 76.5 | 76.5 | 76 | 76 |
| BD - Bottom Bracket Drops (mm) | 45 | 45 | 45 | 45 |
| HT - Head Tube Length (mm) | 95 | 95 | 105 | 115 |
| FL - Fork Length (mm) | 503 | 503 | 503 | 503 |
| R - Reach (mm) | 433 | 453 | 473 | 493 |
| S - Stack (mm) | 585 | 585 | 595 | 604 |
| WB - Wheel Base (mm) | 1126 | 1146 | 1169 | 1193 |
| SH - Stand Over Height (mm) | 730 | 731 | 736 | 738 |
| Siffra | Item Number | Namn | Info | Pieces | Torque NM |
| 2 | 2136001371 | BC - MOUNT | 1 | ||
| 3 | 2298012187 | SCREW | 4 | 5 | |
| 4 | 2298011164 | SCREW | 1 | 5 | |
| 5 | 2300015847 | BOLT | 1 | ||
| 6 | 2300015836 | SCREW | 1 | 16 | |
| 7 | 2221002340 | BEARING | 3803V-2RS 26D*17D*7W | 1 | |
| 8 | 2221002395 | BEARING | 3802V-2RS 24D*15D*7W | 1 | |
| 9 | 2294004882 | WASHER | 1 | ||
| 10 | 2294001180 | WASHER | 1 | ||
| 11 | 2300015773 | SCREW | 3 | 8 | |
| 12 | 2300015784 | BOLT | 1 | ||
| 13 | 2300015795 | BOLT | 1 | ||
| 14 | 2300015803 | BOLT | 1 | ||
| 15 | 2181000342 | SPACER | 1 | ||
| 16 | 2221002254 | BEARING | 6800V-2RS 19D*10D*5W | 3 | |
| 17 | 2294004451 | WASHER | 3 | ||
| 18 | 2300015814 | SCREW | 1 | 8 | |
| 19 | 2300015825 | BOLT | 1 | ||
| 20 | 2221002265 | BEARING | 6801V-2RS 21D*12D*5W | 1 | |
| 21 | 2294004956 | WASHER | 1 | ||
| 22 | 2258005740 | CABLE GUIDE | 1 | ||
| 23 | 2300012509 | SCREW | 1 | 2,5 | |
| 24 | 2300015922 | LOCKING SCREW | 1 | 2,5 | |
| 25 | 2298010442 | SCREW | 1 | 8 | |
| 26 | 2300015911 | SCREW | 1 | 2,5 | |
| 27 | 2294005816 | WASHER | 1 | ||
| 28 | 2232002398 | BASE PLATE | 1 | ||
| 29 | 2232002376 | CHAIN GUARD | 1 | ||
| 30 | 2258004471 | CABLE GUIDE | 1 | ||
| 31 | 2311005673 | DROPOUT | SRAM UDH | 1 |
Highlights
Ability to fit two water bottles into the frame without making the bottles difficult to reach. Perfect for long marathon races and extended trail sessions.
To save weight and further improve the frame stiffness, we have removed the seat-/chainstay pivot point. Instead of a classic bearing, the material properties of the frame allow sufficient flex without having an impact on durability.
All control cables like gear, brake and dropper post cable enter the frame through a specifically shaped headset cap, cleaning up the cockpit area while also keeping them out of harm's way. Only the internally routed cable for the rear shock lockout enters the frame directly into the top tube for extra smooth lockout action.
An additional fixing point behind the head tube offers the option to attach a spare tube, tool or small spare parts safely and securely.
Dra åt skruvarna (använd TORX 30-nyckel) utan att behöva hålla emot från andra sidan – snabbare och enklare åtdragning av viktiga komponenter.
