The ONE-SIXTY 700 gets all the cutting edge enduro performance of our radical new design but with a high-value and fully featured all-aluminium frame. That means hard-hitting modern geometry with our new FAST kinematic suspension that delivers a chaos taming ride alongside quality Marzocchi and Fox suspension. Shimano’s proven 12-speed Deore drivetrain means reliable shifts time after time, while four-piston brakes make short work of keeping everything under control.
Evolution or revolution? How about both? The 2022 ONE-SIXTY is a radical, all-new design that pushes our hard-hitting enduro platform to new heights. Just as well, because once it’s there it’s ready to rip the longest, toughest descents too. Our new suspension system uses a flexstay design with an adjustable rocker, so whether you choose to run it as a full 29er (162 mm travel) or mixed 29/27.5” setup (171 mm travel), the geometry is preserved. There’s a radically steep 79° seat tube angle for goat-like climbing and slack 64° head angle plus 170 mm fork to deal with downhill trail chaos. New sizing allows riders to run a longer or shorter reach frame independently of their height, while suspension becomes more progressive as you size up, all with long-travel dropper posts. Our WIRE PORT cable routing plus reliable threaded bottom bracket round out the package, while carbon frames offer on-board tool storage and FidLock magnetic bottle cages.
- Full aluminium frame with FAST kinematic suspension and radical new enduro geometry
- Mixed or full 29er wheels with AGILOMETER sizing
- Marzocchi Z1 fork and Fox shock, proven Shimano 12-speed drivetrain
- Maxxis Double Down rear and EXO+ front tyres
- Long-travel dropper post
- Powerful 4-piston hydraulic disc brakes
- 29mm inner width
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- rear 27.5" up to Size M, rear 29" L & XL
- 171mm suspension travel mullet / 162mm suspension travel 29"
- material: aluminium
- 29x2.5" max. wheelsize
- 148x12mm axle standard
- BSA bottom bracket standard
- Air
- 170mm suspension travel
- Tapered
- 44mm fork offset
- 29x2.6" max. wheelsize
- platform
- 4 piston
- 203 mm
- 203 mm
- 4 piston
- 4 piston
- Multi Release
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub, 32 spoke holes
- Centerlock
- 32 teeth
- 170 mm for
- Multi Release
- 29x2.5"
- fold
- TR DD 3C MaxxGrip
- 27.5x2.4" XS/S/M 29x2.4" L/XL
- fold
- TR DD 3C MaxxTerra
weighed at frame size MID
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub, 32 spoke holes
- Centerlock
- V-mount
- incl. MERIDA minitool
| Velikost okvirja | XShort | Short | Mid | Long | XLong |
| Tire Sizes | 29/27.5" | 29/27.5" | 29/27.5" | 29" | 29" |
| St Seat Tubes Mm | 400 | 410 | 425 | 445 | 470 |
| Tt Top Tubes Mm | 535 | 562 | 589 | 621 | 653 |
| Cs Chain Stays Mm | 434 | 434 | 434 | 437.5 | 437.5 |
| Hta Head Tube Angles Deg | 64 | 64 | 64 | 64 | 64 |
| Sta Seat Tube Angle Deg | 79 | 79 | 79 | 79 | 79 |
| Bd Bottom Bracket Drops Mm | 7 | 7 | 7 | 27.5 | 27.5 |
| Ht Head Tube Lengths Mm | 95 | 95 | 95 | 105 | 120 |
| Fl Fork Lengths Mm | 581 | 581 | 581 | 581 | 581 |
| R Reachs Mm | 415 | 442 | 470 | 498 | 525 |
| S Stacks Mm | 615 | 615 | 615 | 625 | 638 |
| Wb Wheel Base Mm | 1188 | 1215 | 1242 | 1275 | 1308 |
| Sh Stand Over Height Mm | 735 | 740 | 743 | 740 | 735 |
