eFLOAT HD L 700 EQ



Ready for work or play. Thanks to our heavy-duty front and rear cargo racks, we've boosted the carrying capacity of our low step-through e-bike to new heights. A Bosch CX drive unit makes short work of hills too.
Händler finden

The eFLOAT HD L 700 EQ is the ideal partner for people who need a versatile e-bike for load carrying but don't want the inconvenience of a traditional cargo e-bike. Our robust low-step-through aluminium frame is fitted with a heavy-duty rear rack and headtube-mounted front rack, boosting the cargo carrying capacity to 50 kg, so you can get whatever you want wherever it needs to go. Thanks to 29" wheels with fast-rolling 2.25" tyres, and the Bosch CX drive unit with 800 Wh removable battery, it's a breeze to ride around too.

When life is busy, you need a bike that will help you get the most out of your time. Whether you’re getting to work, taking a cross-town shopping trip or escaping it all to recharge your batteries at the weekend, the MERIDA eFLOAT lineup has a bike for you. An e-bike is an incredibly versatile tool for work or play - but the eFLOAT lineup is more versatile than most thanks to practical and versatile frame designs paired with strong and supportive Bosch drive systems; each will give you more time to do the things that matter. Offering TK trekking, CC SUV-style and HD light cargo options, all bikes come with mudguards, a rear rack, a kickstand, a built-in lock, plus front and rear lights as standard, and each bike has a low step through frame option if you need more clearance. We also use our sleek WIRE PORT cable routing system as standard, so the bikes look as good as they ride. By combining our expertise in aluminium frame design with Bosch’s refined and powerful drive systems, numerous battery options and intuitive display units, we’ve created a trio of models that are subtly adapted to suit your needs.

  • All aluminium low step-through frame with 29" wheels
  • Heavy-duty front and rear racks with 50 kg total carrying capacity
  • Powerful Bosch CX drive unit and removable 800 Wh battery
  • Shimano XT Linkglide 11-speed drivetrain, dropper seatpost
  • Suntour Mobie 120 mm air fork, 2.25" tyres
  • Fully equipped with lights, guards, lock and centre-mount stand
  • material: aluminium
  • 29"x2.4" with fender max. wheelsize
  • 148x12mm axle standard
  • intube
Rahmengrössen S, M
Farbe GUNMETAL GREY (BLACK)
  • Air
  • 120mm suspension travel
  • 29x2.4 max wheelsize
Schaltwerk Shimano XT LG
Schalthebel Shimano SL-MT500-L / Shimano XT
  • material: aluminium
  • 680mm width
  • 15mm rise
Steuersatz Acros ICR MERIDA INTEGRATED neck w/ Blocklock
  • material: aluminium
  • 31.8mm diameter
  • S/M- 70mm L/XL -90mm
Griffe MERIDA EXPERT TK
  • 11-50 teeth
  • 11 speed
  • 110x15mm width front hub
  • 148x12mm width rear hub
  • 28mm inner width
  • material: aluminium
  • Tubeless ready (tubeless tape and valves not included)
  • 29"
  • 15x100mm width front hub
  • 32 spoke holes
  • Centerlock
  • 12x148mm width rear hub
  • 32 spoke holes
  • Centerlock
  • including removeable lever, 6/4mm allen key
Speichen Black stainless
  • 622-55
  • wire
  • reflecting line
Kette Shimano LG500
Pedale VP VPE-541P
  • 34.9mm diameter
  • 0mm setback
  • S/M/L/XL: 150mm travel seatpost

*24% recycled material V-mount

Sattelklemme MERIDA EXPERT
Gepäckträger MERIDA MIK HD Carrier with Spring clip & Spanninga rear light
Schutzbleche Sunnywheel SW-FA311-65A/ SW-FA311-65E1
Parkstütze Massload CL-KA85
Rücklicht Spanninga Commuter Glow Xer integrated in MERIDA MIK HD carrier
Motor Bosch Performance Line CX
Display Bosch Kiox 500
Switch Bosch LED Remote
Bike Frame Geometry Image
Rahmengröße S M
Laufradgröße 28" 28"
ST Sitzrohrlänge (mm) 380 430
TT Oberrohrlänge (mm) 588 605
CS Hinterbaulänge (mm) 475 475
HTA Steuerrohrwinkel (°) 115 120
STA Sitzrohrwinkel effektiv (°) 67.5 67.5
BD Tretlagerabsenkung (mm) 62.5 62.5
HT Steuerrohrlänge (mm) 115 120
FL Gabeleinbaulänge (mm) 538 538
R Reach (mm) 408 425
S Stack (mm) 647 651
WB Radstand (mm) 1176 1194
SH Überstandshöhe (mm) 646 656
Str Stack To Reach Ratio Pc 1.58 1.53
Seat Post Mounting Depth Max Mm 290 300

Um Produktions- und Lieferzeiten möglichst kurz zu halten, sind wir mitunter gezwungen, Spezifikationen in letzter Minute anzupassen. Bitte beachten Sie, dass sich diese Änderungen möglicherweise nicht auf den Produktseiten und Produktbildern widerspiegeln.
