- material: aluminium
- 29x2.35" without fender max./ 29"x2.25" with fender max. wheelsize
- 148x12mm axle standard
- intube
- max. 630 Wh
- 100mm
- Tapered
- 51mm fork offset
- 29x2.4" max wheelsize
- 2 piston
- 2 piston
- 165 mm for all sizes
- 34 teeth
- Shimano FCEM600
- 11-46 teeth
- 10 speed
- V-mount
- material: aluminium
- 34.9mm diameter
- 0mm setback
- 20mm inner width
- material: aluminium
- 29x2.2"
- kevlar bead
- 29x2.2"
- kevlar bead
- 110x15mm width front hub
- 32 spoke holes
- Centerlock
- 148x12mm width rear hub
- 36 spoke holes
- Centerlock
- 85Nm
weighed with 29" wheels and at frame size M
| Frame Size | S | M | L | XL |
| Tire Sizes | 29" | 29" | 29" | 29" |
| St Seat Tubes Mm | 380 | 430 | 480 | 530 |
| Tt Top Tubes Mm | 588 | 605 | 625 | 645 |
| Cs Chain Stays Mm | 465 | 465 | 465 | 465 |
| Hta Head Tube Angles Deg | 67.5 | 67.5 | 67.5 | 67.5 |
| Sta Seat Tube Angle Deg | 74.5 | 74.5 | 74.5 | 74.5 |
| Bd Bottom Bracket Drops Mm | 62.5 | 62.5 | 62.5 | 62.5 |
| Ht Head Tube Lengths Mm | 115 | 120 | 130 | 140 |
| Fl Fork Lengths Mm | 527 | 527 | 527 | 527 |
| R Reachs Mm | 411 | 427 | 445 | 462 |
| S Stacks Mm | 636 | 640 | 650 | 659 |
| Wb Wheel Base Mm | 1165 | 1183 | 1204 | 1225 |
| Sh Stand Over Height Mm | 719 | 750 | 794 | 835 |
Category Highlights
Shimano's EP8 motor offers a perfectly balanced power delivery with up to 85 Nm and has further improved on size, weight, noise and motor drag. The new 630 Wh battery is perfectly integrated into the hydroformed down tube and delivers an impressive range for even longer detours home.
Due to the integrated battery, we were able to offer water bottle cage fixing points, allowing bottles or accessories like a lock or pump to the frame to be fitted into the main frame triangle. Great if you want to keep your back free of hydration packs and backpacks.
La géométrie du eBIG.NINE et du eBIG.SEVEN suit un principe simple : aussi sportive que possible et aussi confortable que nécessaire. Pouvoir se rendre au travail rapidement le matin ou une petite embardée sur le chemin du retour? Pas de problème, ces vélos sont là.
Les modèles équipés de "K-Mount" ont un socle de montage intégré sur les bases arrières pour permettre le montage d'une béquille latérale MERIDA. Les vélos avec "C-Mount" sont équipés d'oeillets et permettent l'ajout d'un porte-bagages. Les vélos marqués "F-Mount" sont préparés pour le montage d'un garde-boue.
